BƠM HỒ BƠI ESPA
Mã sản phẩm: BHB11
Giá: Liên hệ
Multi-stage centrifugal pumps, specifically designed to activate automatic bottom-cleaning systems that require intake pressure.
Compatible with chlorinated, salted and ozonised water.
Continuous service with built-in thermal protection.
Multi-stage centrifugal pumps, specifically designed to activate automatic bottom-cleaning systems that require intake pressure.
Compatible with chlorinated, salted and ozonised water.
Continuous service with built-in thermal protection.
Series features Multipool N:
- Equipment
- Check valve: No
- Draining plug: Yes
- Fittings: Screw
- Flow adjustment valve: Yes
- Pressure gauge: Included
- Support base: Included
- Electrical characteristics
- Electrical isolation: F Class
- Motor speed operation: Constantly speed
- Motor type: Asynchronous
- Protection rating: IP55
- Reset: Automatic
- Service factor: S1
- Service type: Continuous
- Manufacturing characteristics
- Discharge connection type: Nut
- Discharge diameter: 1" G
- Impeller type: Closed
- Motor cooling: Fan
- Stages: Multi stage centrifugal pump
- Suction connection type: Nut
- Suction diameter: 1" G
- Tightness by: Mechanical Seal
- Materials
- Diffuser: PPO + 30% GF
- Discharge body: Polyamide + 30% GF
- Impeller/s: Stainless Steel AISI 316
- Mechanical seal: Aluminium-Graphite
- Mechanical seal bracket: PP + 30% GF
- Motor casing: Aluminium
- Motor shaft: Acero inoxidable AISI 431
- Nuts and bolts: Stainless steel AISI 304
- Pump shaft: AISI 431
- Suction body: Polyamide + 30% GF
- Support base material: PP + 30% GF
- Usage limits
- Liquid temperature (ºC): Min: 4 - Max: 35
- Maximum no. of motor start-ups (start-ups/minute): 0,50
- Maximum working pressure (bar): 6
